2026 BWS TRI-AXLE STEEL DROP DECK

FET INCLUDED in this price! Length 48' Width 102" Top Deck Length 11' Main Deck Length 37' Main Deck Height 41" Weight 14,875 Lbs. +/-2% - GVWR 115,000 Lbs Flat Body Bulkhead None Floor 1 1/8" Apitong Chain Tiedowns 15 Pair 4-Way Chain Slots, Evenly Spaced Front/Rear Member Steel Side Rail 6" @ 8.2 Steel Channel Pipe Spools Double Winch Track Roadside Sliding Winches 12 Add. Receptacle ISO 7-Way Side Rail Lights Three (3) Per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights 3rd Tail Light at Rear Mud Flap Brackets Behind Rear Axle Only Suspension # of Axles 3 Suspension Type Air Ride Suspension Brand Ridewell Suspension Setting 61" Between Axles, Rear Axle at Rearmost position Lift Axle Center Axle Electric Dumpvalve Rear Axle - Wired to Center Pin of Aux 7-Way Manual Dumpvalve Yes Tire Brand Saulin S637 Tire Size 275/70R22.5 Wheels Steel, Painted White UnderFrame King Pin Setting 18" 5th Wheel Condition 3/8" Coupler Plate Cross Member Center 4" I-Beams on 16" Centers Coil Package Yes Landing Gear Two Speed Paint Black Weight Ratings 80,000 Lbs. in 4' Beam Rating 88" Swing Clearance Aluminum Air Tanks Brake Dust Covers 15 Pair 4-way Chain Slots in Deck
