2025 XL Specialized XL80SA

Length 53' Width 102" Top Deck Length 10' 5" Full Width Neck Main Deck Length 42' 7" Main Deck Height 38" Loaded Deck Height Flat Body Floor 1 3/8" Apitong Chain Slots 24" on Center on Both Sides & Down Center Load Angle 6 1/2 Degree Side Rail Perimiter Beam - Steel Toolbox Two (2) Top of Neck, Top Opening, Alum Lids Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Amber Strobe as 3rd Tail Light Hydraulics Hydraulic Winch WARN Winch, 20,000 lbs. Cable 100' of 9/16" Cable with Loop Wireless Remote Six Function Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 50" Axle Spacing Tire Size 245/70R17.5 Wheels Steel, Painted White UnderFrame King Pin Setting 21" Cross Member Center 4" & 3" I-Beams on 8" Centers Landing Gear Two Speed Paint Black Weight Ratings 80,000 GVWR - 50,000 in 10' Comments California Legal 82" Swing Clearance Chain Drops on 48" Centers Both Sides of Top Deck Hydraulics Run Off Wet Kit (15 to 20 GPM Required) Planetary Drive Recessed Cable Roller Manual Dump Valve on All Axles Limit Chains on Both Axles
