2024 Heil 7000 GALLON MC-407 SS TANK, INSULATED W HEAT

Total Capacity 7,000 Gallons Compartment Sizes One - 7,000 Shape/Style Straight Round MC Code DOT 407 Baffles None Barrel Material 316 SS Pressure Rating Operating Pressure - 30 PSI Insulation-Tank Fiberglass, 5" compressed to 4" Heat Yes, 150 PSI, 3-Piece Channel Welded to Bottom Primary Valve-EV Betts 4"x3" T316 External Hydraulic w Teflon Seat EV Operators Betts Hydraulic Pump #HP-46982ALSL Secondary-Discharge Betts 3" T316 Hydrolet, QRB, 90 Degree Outlet Piping 3" Stainless Steel Spool Piece at Rear of Trailer Vapor Recovery 3" SS at Spilldam w 2" SS Pipe Down R/S, 2" Outlet Overfill Protection None Pump None Venting Vacuum - 4" Betts Combo Vacuum Pressure Vent Pressure Line 1" SS from front to Spill Dam w Jumper Hose Ladder Curbside, SS Ladder Catwalk 12" Alum C/S Dam, 19" Alum Top Center to Cleanouts Cleanouts Three (3) 3" SS Threaded Nozzle with T316 Cap Hose Tubes Two (2) 21' x 8" Aluminum, One per Side at Rear Hose Tray None Fenders Aluminum, Front & Rear Placards Four (4) ALuminum Slide-In Rear Light Pkg (2) Stop/Tail, (3) Clearance # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Intraax AANT-23K Suspension Setting 49" Closed Tandem Manual Dumpvalve Auto 4-Bag Dump Valve Tire Brand Cooper RM872 Tire Size 11R22.5 Wheels Aluminum Landing Gear Jost, Two-Speed Suspension Frame Stainless Steel Heat Plumbing with Traps & 1/2" Pressure Relief Provisions for Intransit Heat, to Include Ball Valves Weld Finish: W3 Inside including Manhole, Collars & All Nozzles Design Temperature - 300 Degrees Betts 20" SS Manhole 22 Gauge SS Jacket, Bright Finish
