2024 Wabash Combo Low Pro 17.5

FOR RENT/LEASE ONLY! Length 53' Width 102" Top Deck Length 10' Main Deck Length 43' Main Deck Height 36" Weight 11,572 Lbs. (+/-3%) Floor Aluminum Nailing Strips Four (4), Apitong Front/Rear Member Aluminum Side Rail Aluminum Pipe Spools Double Lock-Rite Multi-Position Tie Downs, 10 Pair Winch Track Roadside with Tie Bar on Curbside Sliding Winches 12 Add. Receptacle 7-Way ISO with 4-Wire Cable Ran to Suspension Side Rail Lights Five (5) per Side, LED Rear Lights (3) Stop/Tail, (3) Clearance Mud Flap Brackets Behind Front & Rear Axle # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson HT250US Suspension Setting 60.5"-121" Rear Axle Slider/Front Fixed Electric Dumpvalve Rear Axle Tire Brand Cooper RM272 Tire Size 245/70R17.5 Wheels Aluminum/Steel King Pin Setting 18" Cross Member Center 12" - Steel Landing Gear Jost, Two-Speed Paint Black Weight Ratings 734 (73,000# in 4') Low Deck Beam California Legal when Axle Slid Forward Reduced Camber Beams Container Locks: - (2) 20ft, (1) 40 ft, & (1) 20ft. Heavy Duty Container Twist Locks Setup - (10 Pair) Lock-Rite Multi-Position Tie Downs Hendrickson TIREMAAX PRO Inflation System FET Included in Price
