2025 Fontaine RENEGADE XN20

Length 53' - 77' Width 102" Top Deck Length 11'11" Main Deck Length 32' closed/56' open Main Deck Height 20" with 6" ground clearance Rear Deck Length 9'2" Weight 24,750 lbs. +/- 3% Unit Description Double Drop Extendable Flat Body Compatibility Designed to Accept 3rd Axle Flip Floor 1 3/8" Apitong Ramps None, Front Deck Sloped w Traction Cleats Side Rail Steel Outriggers 16 Pair D-Rings 12 Pair Side Rail Lights 8 per Side Including Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Yes Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" with Five Ride Height Positions Pony Motors 13 HP Pony Motor Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54.5" Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Aluminum Outer / Steel Inner UnderFrame King Pin Setting 16" Cross Member Center 24" Paint Black Weight Ratings 40 Ton
