2027 Fontaine 55H-Dsr

FET included in the price. Flip Axle not included. Length 53' 0" Width 102" Top Deck Length 11' 11" Gooseneck Main Deck Length 27' Main Deck Height 14.5" at Side Rails; 22" at Main Beams Weight 22,925 Lbs. +/-3% Unit Description Magnitude 55DSR Flat Body Compatibility Designed to Accept Flip Neck Extension & Flip Axle Floor 1.5" Nominal Wood - Side Rails Only Side Rail Drop Side Rail - Steel Outriggers 13 Pair, Removable Swing Type D-Rings 14 Pair Toolbox Two Covered Trays Between Mainbeams Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Amber Strobes with Battery Power Flag Holders One Pair at Front of Deck, One Pair on Bumper Modular Connection Fixed Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Axle Spacing Lift Axle Air Lift Rear Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels Aluminum/Steel Liquid Filled Gauge Yes UnderFrame Paint Black Weight Ratings 55 Ton in 12' Length Comments 102" Swing Clearance Low Boom Well Chain Lift Axle on Front Axle Override Chains on 2nd & 3rd Axles
