2026 Xl Specialized 55 Ton - 15" Ldh Galvanized

55 Ton, 15" Loaded Deck Height, Trailer is Galvanized with Side Webs Painted Black. Have the low deck height of a drop side rail with more versatility. Length 53' Width 102" Top Deck Length 13' Main Deck Length 26' Main Deck Height 15" Loaded with 4.5" Ground Clearance Rear Deck Length 14' Weight 23025 lbs. +/- 3% Compatibility Flip Axle Connections at Rear Floor Apitong Ramps 31" Front Ramps Side Rail Perimiter Beam - Steel Outriggers 13 Pair D-Rings 8 Pair Toolbox Main deck behind gooseneck Strobe Lights Yes with battery back up Flag Holders 2 Pair Rear Bogie 14' with open wheel wells Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 51" with Five Ride Height Positions # of Axles 3 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54.5" axle spacing Lift Axle Air Lift Rear Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels Aluminum/Steel Liquid Filled Gauge Yes King Pin Setting 16"/42" Cross Member Center 12" alternating centers Paint Entire Trailer Galvanized, Sides Painted Black Weight Ratings 55 Ton in 12' Length 110" and 84" swing clearance Work light on gooseneck 13 pair of key hole chain drops on outer beam of main deck Open boom trough 2 stake pockets at rear for wide load sign Bucket well at rear of main deck with plate on bottom w/ 4 Flat D-Rings 4 way plug at rear 2 Chain Drops per Full Width Bolster
