2027 Fontaine Renegade N12

**FET Included in Price** Length 53' Width 102" Top Deck Length 11' 2" Main Deck Length 32' 11" Main Deck Height 12" with 4" Ground Clearance Fully Loaded Rear Deck Length 8' 11" Weight 20,665 Lbs. +/- 3% Unit Description 30-Ton Mini-Deck Flat Body Compatibility Designed to Accept 3rd Axle Flip Floor 1 3/8" Apitong Ramps None - Front Deck Sloped Down w/ Traction Cleats Side Rail Steel Outriggers None D-Rings 12 Pair Side Rail Lights Six (6) per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders Two (2) Pair Modular Connection Fixed Rear Bogie Rear Bogie Platform w/ 1 1/8" Wood Floor Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Suspension # of Axles 2 Suspension Type Air Ride Suspension Setting 50" Closed Tandem Raise & Lower Valve Mechanical Ride Height Control Valve Wheels Polished Aluminum Outside / Steel Inside Liquid Filled Gauge Yes UnderFrame Cross Member Center 18" Paint Black Weight Ratings 30 Ton in 16' Length Comments Mini Boom Trough & Traction Cleats Installed on Sloped Bogie Ramp Override Chains on Axles 1 & 2 Stainless Steel Bumper Insert 7 Variable Ride Heights
