2027 Fontaine Renegade

Length 47' 11" Top Deck Length 9' 10" Width 102" Main Deck Height 20" with 6" Ground Clearance Main Deck Length 29' Rear Deck Length 9' 2" Weight 16,035 Lbs. +/- 3% Unit Description 40-Ton Mechanical Detachable Double Drop Lowboy Flat Body Compatibility Designed to Accept 3rd Axle Flip Floor 1 3/8" Apitong Ramps None - Front Deck Sloped Down w/ Traction Cleats Side Rail Steel Outriggers 14 Pair Removable Swing Type, 1 Pair Hook-On Type D-Rings 9 Pair Side Rail Lights Nine (9) per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Suspension # of Axles 2 Suspension Type Air Ride Suspension Setting 54 1/2" Closed Tandem Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 255/70R22.5 Wheels Polished Aluminum Outside / Steel Inside UnderFrame Cross Member Center 12" Paint Black Weight Ratings 40 Ton in 16' Length Comments Mechanical Detachable w/ Removalble Guide Rollers Combination Figure-8 Plate - Provides 50" & 52" Loaded Fifth Wheel Heights Swing Radius of 81" Full Width Gooseneck Platform with 1 1/8" Wood Floor Aluminum Fenders at Rear of Gooseneck Mini Boom Trough & Traction Cleats Installed on Sloped Bogie Ramp Liquid Filled Gauge Stainless Steel Bumper Insert
