2025 Heil 1600 SUPER FLO

Length 42' Width 102" Weight 11,010 Lbs. +/-3% Body Tank Total Capacity 1600 Cu Ft # of Hoppers Four Hopper End Frames Aluminum Manholes Four (4) Barrel Material Aluminum Body Pipe Aeration Three (3) BTI Aerators per Hopper Piping 4" Aluminum, Schedule 40 Tees 6"x4" BTI Aluminum w/ 6" Gravity Drop Product Valves 6" BTI Black Maxx Butterfly Valves Rear Discharge Aluminum - Under Axles Top Air 3" Aluminum Pipe w/ 3" BTI Valve Body-Accs. Ladder Aluminum, Centered at Rear Hose Tubes Two (2) 8"x21' Aluminum, D/S Rear, Rear Door Fenders Aluminum, Front & Rear Gauges Inside Cabinet on Front of D/S Rear Fender Rear Light Pkg (2) Stop/Tail, (3) Clearance Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Intraax AAT-23K Tire Size 11R22.5 Wheels Aluminum, Outside Polished UnderFrame Landing Gear Jost, Two-Speed, Aluminum Housing Paint Black Overall Height 12' 11" with Manholes Closed Class II Interior Finish. Interior Welds Polished. 3" Aluminum Aeration Line, Roadside One (1) 6" Aluminum Rear Load Line, Extended into Barrel Appr. 7' Galvanized Suspension Hangers Hendrickson Maxx22T Disc Brakes 4S/2M ABS with Roll Stability

Axle:

Tandem

Composition:

Aluminum

Wheels:

All Aluminum

Width:

102

Tires:

11R22.5

Length:

492.000000000000

Fixed Axle:

Fixed

Suspension:

Air Ride
