2020 XL Specialized 80HDGS

FOR RENT/LEASE ONLY!! Length 49' Width 102" Top Deck Length 11' w/ Full Width 1 1/8" Apitong Decking Main Deck Length 29' Main Deck Height 18" Rear Deck Length 9' Weight 18,500 Lbs. +/- 3% Flat Body Compatibility Flip Axle Connections at Rear Floor 1 3/8" Apitong - Side Rails Only Ramps 31" Front Flip Ramps Outriggers 12" Swing Out on 24" Centers, w/ Double at Front D-Rings 6 Bent D-Rings per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights 4" Amber Strobe as 3rd Tail Light Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 51" with Five Ride Height Positions Pony Motors 13 HP Honda, Set UP with Dual Hydraulics Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54" Axle Spacing Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Aluminum Polished Outside / Steel Inside Liquid Filled Gauge None UnderFrame King Pin Setting 16" Cross Member Center 8" & 4" I-Beams on 12" Alternating Centers Paint Black Weight Ratings 80,000 lbs. distributed 86" Swing Clearance 6" Ground Clearance Chain Drops on 24" Centers on Main Deck Full Width Apitong Decking on Rear Deck 40" Loaded Rear Deck Height Two (2) Flat D-Rings at Rear
