2027 Fontaine 55Mx

*FET Included in Price** Length 55' 4" Closed, 76' 4" Open Width 102" Main Deck Length 29'4" Closed, 50'4" Open Main Deck Height 20" Weight 26,900 lbs. Unit Description Magnitude 55MXT Flat Body Compatibility Designed to Accept 23" Neck Extention & Flip Axle Floor 2" Apitong Ramps None, Front of Deck Sloped Down Outriggers 14 pair - Removable Swing Type / 1 pair removable D-Rings 12 pair Toolbox 1 Fully Covered Tray in Rear of Deck Side Rail Lights 3 Marker Lights per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders Two (2) Pair Total, Fron of Deck & Bumper Modular Connection Modular (Main Deck Disconnects from Bogie) Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Pony Motors Honda 13HP Pony Motor Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Lift Axle Front Axle Chain Lift, Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels (6) Polished Alum (6) Steel Disc Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" Cross Member Center 12" Paint Black Weight Ratings 55 Ton in 12' Length Designed to Accept 51/60 Rear Axle, EQ1 Spreader, and/or 35" Flip Box 7-Ride Height Positions Removable Kingpin at 102" Radius Low Boom Well
