2026 Dorsey BEAVERTAIL

FET Included in the Price! Length 53' - Including Beavertail Width 102" Top Deck Length 10' 6" Main Deck Length 38' 1" Main Deck Height 41" Loaded Deck Height Weight 13,990 Lbs. (+/- 3%) Inspection New Flat Body Floor 1 1/8" Apitong Front/Rear Member Steel Beavertail 53" Steel with Traction Bars Ramps Two (2) Spring Assisted, 3' 11" Long Side Rail Steel Pipe Spools Double Winch Track Roadside Sliding Winches 12 Side Rail Lights Three (3) per Side, LED Rear Lights (3) Stop/Tail, (3) Clearance Mud Flap Brackets Behind Front & Rear Axle Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Intraax 23K Suspension Setting 10' 2" Manual Dumpvalve Yes Tire Brand Double Coin Tire Size 255/70R22.5 Wheels Steel UnderFrame King Pin Setting 24" Cross Member Center 18" Top Deck, 12" Main Deck Landing Gear Two Speed Paint Black Weight Ratings 80,000 GVWR - 60,000 in 10' Comments Center pipe installed, capable of adding future 3rd ramp "C" Channel winch track. No tie bar. Side rail is deep enough to accept a flat hook from a strap.
