2026 Fontaine 60LCC

Length 52'3" Width 102" Main Deck Length 26' Main Deck Height 18" Weight 24,051 lbs. Unit Description Magnitude 60LCC Flat Body Compatibility Designed to Accept 35" Neck Extention & Flip Axle Floor 2" Nominal Wood - Side Rails Only Ramps Manual Front approach ramps Outriggers 13 pair - Removable Swing Type / 2 pair removable D-Rings 19 pair Toolbox 2 Trays - fully Covered between main beams Side Rail Lights (3) Marker LIghts per Side incl. Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders 1 Pair Modular Connection Fixed Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Pony Motors None Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Lift Axle Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels (6) Polished Alum (6) Steel Disc Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" Cross Member Center 24" Centers Paint Black Weight Ratings 60 Ton in 13' Length w/ Closed 4-Axle Compatibility with Spreader Bar and/or 35" Flip Box 7 Variable ride Height Positions 102" Swing Radius Removable Kingpin at 102" Radius Low Boom Well Chain Lift Axle on Front Axle

Axle:

Tri

Detachable:

Detachable

Composition:

Steel

Wheels:

Aluminum/Steel

Width:

102

Tires:

22.5

Length:

636.000000000000

Fixed Axle:

Fixed

Suspension:

Air Ride

Wet Kit:

1

Floor Type:

Wood Floor
