2023 Fontaine WORKHORSE 55LCC

FOR RENT/LEASE ONLY! FLIP AXLE NOT INCLUDED! Length 53' Width 102" Main Deck Length 26' Main Deck Height 18" Weight 23,331 lbs. Unit Description Workhorse 55LCC Compatibility Flip Axle Connections at Rear Floor 2" Nominal Wood - Side Rails Only Ramps Manual Front approach ramps Outriggers 12 pair - Removable Swing Type / 2 pair removable D-Rings 19 pair Toolbox 2 Trays - fully Covered between main beams Side Rail Lights (3) Marker Lights per side incl. Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders (1) pair mounted in Rear Bumper Modular Connection Fixed Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 10 Ride Height Position, 50" Pony Motor # of Axles 3 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54.5" Lift Axle Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels (6) Polished Alum (6) Steel Disc Liquid Filled Gauge Yes King Pin Setting 16" or 35" Cross Member Center 24" Centers Paint Red Weight Ratings 55 Ton in 13' Length Weld On Load Bearing Wheel Covers Hammer Plate (16"x60"x1/2") installed over recessed crossmembers. Perforated plate under hammer plate forming two storage areas. 2 lashing rings located in last two deck sections.

Axle:

Tri

Detachable:

Gooseneck Detachable

Composition:

Steel

Wheels:

Aluminum/Steel

Width:

102

Tires:

275/70R22.5

Length:

636.000000000000

Fixed Axle:

Fixed

Suspension:

Air Ride
