2018 Fontaine 55 TON DROP SIDE RAIL

Length 53' Width 102" Top Deck Length 11'11" Main Deck Length 26' Main Deck Height 14.5" Loaded at Outer Rail Rear Deck Length 14'1" Weight 22,667 Lbs. +/- 3% Inspection C- WV 1/26 Flat Body Compatibility Designed to Accept 23" Neck Extention & Flip Axle Floor Wood Side Rail Perimiter Beam - Steel Outriggers 13 Pair - Swing Out D-Rings 14 Pair Strobe Lights Yes - No Battery Back Up Flag Holders Yes Rear Bogie Covered Load Bearing Wheel Covers Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" with Five Ride Height Positions Suspension # of Axles 3 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54" Lift Axle Air Operated - Rear Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Brand Continental HSR2 Tire Size 275/70R22.5 Tire % 70% - Matched Virgins Wheels Aluminum/Steel - Hub Pilot Brake % F&M - 15% R-35% UnderFrame 5th Wheel Condition OK Cross Member Center 24" Paint Black Paint Condition OK Weight Ratings 55 Ton Dual King Pin Settings at 81" and 102" Swing Clearance
