2026 XL Specialized XL110HDGS18 GUARDIAN - 55-TON

Length 53' Width 102" Main Deck Length 26' Main Deck Height 18" Rear Deck Length 14' Weight 22,557 Lbs +/- 3% - GVWR 132,750 Lbs Flat Body Compatibility Accepts 4th Axle Flip & Spreader Bar Floor 1 3/8" Apitong, Raised - Center Open Ramps 31" Front Flip Ramps Side Rail 12" Fabricated I-Beam Outriggers Swing Out Outriggers on 24" Centers D-Rings Seven (7) Bent "D" Rings per Side Toolbox In Front of Main Deck w 4 Flat D-Rings Side Rail Lights Five (5) Lights per Side Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders (1) Pair in Main Deck, (1) Pair at Rear Modular Connection Fixed Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 51" with Five Ride Height Positions Pony Motors None Suspension # of Axles 3 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54.5" Lift Axle Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 275/70R22.5 Wheels Aluminum Outer / Steel Inner Liquid Filled Gauge Installed UnderFrame King Pin Setting 16" & 42" Cross Member Center 12" Centers Paint Black Weight Ratings 55 Ton in 12' Length Comments 110" & 84" Swing Clearance Grote Trilliant Work Light on Gooseneck 4 Flat D-Rings in Bucket Well Chain Drops on 24" Centers per Side 2 Flat D-Rings on Main Beams at Front 2 Flat D-Rings on Main Beams at Rear 2 Chain Drops on Each Bolster 2 Stake Pockets in Tail Channel for Wide Load Sign Bucket Well at Rear Deck w/ Plate on Bottom - 4 Flat D-Rings 4-Way Receptacle at Rear
