2026 Fontaine WORKHORSE 55LCC

FET INCLUDED IN PRICE! Length 53' Width 102" Main Deck Length 26' Main Deck Height 18" Weight 21,831 lbs. Unit Description Workhorse 55LCC Compatibility Flip Axle Connections at Rear Floor 2" Nominal Wood - Side Rails Only Ramps Manual Front approach ramps Outriggers 12 pair - Removable Swing Type / 2 pair removable D-Rings 19 pair Toolbox 2 Trays - fully Covered between main beams Side Rail Lights (3) Marker Lights per side incl. Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders (1) pair mounted in Rear Bumper Modular Connection Fixed Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Pony Motors None # of Axles 3 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54.5" Lift Axle Rear Axle Air Lift Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels (6) Polished Alum (6) Steel Disc Liquid Filled Gauge Yes King Pin Setting 16" or 35" Cross Member Center 24" Centers Paint Black Weight Ratings 55 Ton in 13' Length 108" Swing Radius Removable Kingpin at 89" & 108" Radius Chain Slots Located on Side Rails Low Boom Well Chain Lift Axle on Front Axle Hammer Plate (16"x60"x1/2") installed over recessed crossmembers. Perforated plate under hammer plate forming two storage areas. 2 lashing rings located in last two deck sections.
